LRES3029PF-OCP is a dual-port 25G Ethernet network adapter with OCP3.0 SFF structure developed by Shenzhen Lianrui Electronics Co., LTD based on Intel E810 chip. Virtualization applications with 1/10/25G connection to meet network infrastructure, based on the RDMA feature of iWARP, RoCEv2 to achieve direct memory to memory data communication between applications over the network.
LRES3029PF-OCP also has ADQ technology by using specific resources for key work, ADQ uses optimized application thread to device data path to achieve specific application data control, signaling and rate control, improve the scalability and predictability of server running programs; At the same time, THE DDP technology used by LRES3029PF-OCP is enhanced in data cloud computing and virtualized workloads. DPDK is more efficient in packet forwarding and packet processing, and has more flexibility.
LRES3029PF-OCP can be used to connect at 1/10/25g speed, which is enough to cope with different link modes and specifications. With flexibility and high performance, users are more assured in the choice of use.
Specifications
Controller
Intel E810
Cable medium
Optical Fiber
Fiber Type
25GBASE-SR、25GBASE-LR、25GBASE-Cu
10GBASE-SR、10GBASE-LR、10GBASE-Cu
1GBASE-SR、1GBASE-LR、1GBASE-Cu
Bracket Height
SFF
Power(W)
6.936 W
Power(W)
10.14 W
System Support
Windows 10 /11
Windows Server 2016 /2019 /2022
Deepin 20 /20.6
VMware ESXi 6.7 /7.0
Galaxy Unicorn v10
NeoKylin 7.6
RHEL/CentOS 7.3 /7.6 /7.9
RHEL/CentOS 8.2 /8.3 /8.4
Ubuntu 20.04.1
SUSE 12.5
FreeBSD 12.2
ZTE New Fulcrum 5.0.5 /3.2.2
Asianux Server v7.0
Zhongke Fangde server operating system
iKuai router
Bus Type
OCP3.0 SFF
Data rate per port
1/10/25Gbps
Connector
2*25G SFP28
Power Supply
PCIe
Technical Features
Protocol Support
IEEE 802.3by-2016 25GBASE-X Ethernet
IEEE 802.3ae 10GBASE-X Ethernet
IEEE 802.3z 1000BASE-X Ethernet
IEEE 802.3ap
IEEE 802.3ad
IEEE 802.1Q
IEEE 802.1Qaz
IEEE 802.1Qbb
IEEE 802.1Qbg
IEEE 1588 PTP
IEEE 802.3az - Energy Efficient Ethernet
PXE
No
Wol
No
Jumbo Frames
Yes
VMDq、SR-IOV
No
UEFI
Yes
NCSI
Yes
RDMA/VF
iWARP、RoCEv2
ESD_Contact discharge
±8KV (Class A)
ESD_Air discharge
±15KV (Class C)
ESD test classification
Class A: Normal performance within the limits specified by the manufacturer, commissioner, or purchaser.
Class B: Temporary loss or reduction of function or performance, but can be recovered by itself after the disturbance stops, without operator intervention;
Class D: Temporary loss or degradation of function or performance that requires operator intervention to restore;
Class D: irrecoverable loss of function or performance degradation due to damage to device hardware or software, or loss of data.
Environment Features
Operating Temperature
0℃ to 105℃ (32 ℉ to 221 ℉)
Storage Temperature
-40 ℃ to 115 ℃ (-40 ℉ to 239 ℉)
Storage Humidity
Maximum: 90% non-condensing relative humidity at 35 ℃
Certification
FCC, CE, RoHS
Physical Features
PCB Size(mm) |
115*76*1.6 |
Package Size(mm) |
179*150*30 |
Weight(g) |
* |
LED Indicators
1Gbps
|
LINK |
Orange Link |
ACT |
Orange Link + Green Blink |
|
10Gbps
|
LINK |
Orange Link |
ACT |
Orange Link + Green Blink |
|
25Gbps
|
LINK |
Green Link + Green Link |
ACT |
Green Link + Green Blink |
Order Information
P/N |
Description |
LRES3029PF-OCP |
OCP3.0 Dual-port 25G SFP28 Ethernet Network Adapter (Intel E810 Chip Based) |
PS: Above details are only for reference, if there is any change,no prior notice.
