Dual-port 100G PCIe 4.0 x16 network adapter with RoCEv2 and NVMe-oF support for AI/ML clusters.
When AI training clusters face network bottlenecks, latency-sensitive GPU workloads suffer from inefficient data movement. The LRES1162PF-2QSFP56 PCIe 4.0 x16 Dual-Port 100G Network Adapter addresses this by delivering ultra-low latency connectivity essential for synchronized distributed computing.
Equipped with dual QSFP56 ports supporting 10/25/40/50/100Gbps speeds, the adapter provides a total bandwidth of 200GbE. This massive throughput eliminates network congestion, enabling seamless scaling of GPU-intensive applications. Support for RoCEv2 and NVMe-oF further accelerates remote storage access and inter-node communication, critical for modern cloud infrastructure.
Ideal for data centers and high-performance computing, this HHHL form factor card integrates easily into standard servers. With robust protocol support including VXLAN and Geneve, it ensures efficient traffic handling and network isolation. Choose the LRES1162PF-2QSFP56 to maximize performance in demanding AI and virtualized environments.
Dual QSFP56 ports support 10/25/40/50/100Gbps speeds with 200GbE total bandwidth for maximum throughput.
Leverages PCIe 4.0 x16 host interface to ensure low-latency data transfer and eliminate bottlenecks.
Enables remote direct memory access and NVMe over Fabrics for accelerated storage and AI/ML workloads.
Facilitates direct data exchange between GPU and network adapter, reducing CPU overhead in HPC environments.
Supports SR-IOV, VXLAN, Geneve, and NVGRE for efficient network isolation and management in cloud platforms.
Compatible with Windows, Linux distributions (RHEL, Ubuntu, CentOS), VMware, and FreeBSD for flexible deployment.
High-quality optical modules and cables for optimal compatibility with your network adapter.
Complete technical details for integration and deployment planning.
| Host Connector | PCIe 4.0 x16 |
|---|---|
| Connectors | QSFP56 |
| Port Count | Dual-port |
| Link Speed | 10/25/40/50/100Gbps |
| Total Bandwidth | 200GbE |
| IEEE Standards | IEEE 802.3cd, IEEE 802.3bj, IEEE 802.3by, IEEE 802.3ae, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Q, IEEE 802.1p, IEEE 1588v2, IEEE 802.3az |
|---|
| Supported Features | PXE, UEFI, RoCEv2, NVMe-oF, SR-IOV, 1588 PTP, Jumbo Frames (9.9KB), RDMA, GPU Direct, VXLAN, Geneve, NVGRE |
|---|
| Form Factor | HHHL |
|---|---|
| Adapter Power (Max 100% traffic) | 30.67W |
| Adapter Size | 167.7*68.9mm |
| Operating Temperature | -10°C to 60°C |
| Storage Temperature | -40°C to 70°C |
| Storage Humidity | Maximum: 90% non-condensing relative humidity at 35°C |
| Operating Systems | Windows, Windows Server, Deepin, OpenKylin, RHEL/CentOS, OpenEuler, Ubuntu, AIce, FusionOS, ATLServer, KylinOS, VMware, FreeBSD, Debian, Rocky, SUSE, REDOS |
|---|
| Certifications | FCC, CE, RoHS |
|---|
