LRSU9A72-2C

PCIe 2.0 x1 to dual Type C USB expansion card (based on Renesas upd720202)
Key Features

Datasheet:

  • Overview
  • Specifications
  • Ordering
  • Driver
  • Relative Products

Model

LRSU9A72-2C

Controller

Renesas upd720202

Baffle height

Half-height and full-height configuration

Power consumption (max)

500mW

Port type

TYPE C interface/PCIE2.0 X1

Number of ports

2

PCIe bus

PCI Express2.0/USB3.0

Speed

5Gb/s

Power supply

PCIe power supply/external SATA power supply

ESD test

Contact discharge

±8KV

Operating system support

* Windows 7/8/10/11

* Windows Server 2008/2012/2016

* Windows Server2019/2022

* RHEL/Centos7.6/7.9/8.2/8.3

* Deepin 15.11/20/20.6

* Ubuntu 18.04.5/20.04.1

* VMware ESXi 6.5/6.7/7.0

* SUSE 12.5

* FreeBSD 12.2

* 中兴新支点 3.2.2/5.0.5

* 红旗 Asianux 操作系统 V7.0

* 银河麒麟 V10 SP1

* 中标麒麟 7.6

* 中科方德桌面操作系统 4.0

* 中科方德服务器操作系统

* 统信 UOS 20

* 一铭操作系统

* 开源麒麟 0.7.5

Operating temperature

0℃ to 70℃ (32℉ to 158℉)

Storage temperature

-25℃ to 80℃ (-13℉ to 176℉)

Storage humidity

90% non-condensing relative humidity at 35℃

Certification

FCC,CE,RoHS
