LREC9801BF-SFP+ is a PcIe x8 2.0 10Gbps Single/Dual Port Ethernet Fiber Server Adapter based on Intel 82599 Chipset. The design of this server adapter card is mainly for servers and high-end devices.
The Server Adapter LREC9801BF-SFP+/ LREC9802BF-2SFP+ Provides a number of hardware optimization features including I/O virtualization, and supports a unified network, transforming the data center with outstanding reliability, scalability, and mobility.
LR-LINK PCIe x8 Quad-port 10G SFP+ Ethernet Server Adapter: LREC9804BF-4SFP+
Controller |
Intel 82599 |
Transmission rate per port |
10GbE |
Network Standard Physical Layer Interfaces |
10GBASE-SR, 10GBASE-LR,10G SFP+ Coppe, |
10G SFP+ DAC, 10G SFP+ AOC |
|
Operating Temperature |
0°C to55 °C (32 °F to 131°F) |
Network Virtualization |
FCoe, DPDK |
LED Indicators OPERATION |
Link/Activity LED: off = No Link; on = Link;GreenBlinking = Activity |
Operating System Support |
Windows Server 2012 R2/2012 /2008 R2/2008/2003/10/8.1/8/7 |
Linux kernel 2.6.30 or greater (x86_64) (w/ SR-IOV support) /FreeBSD 7.2 or laster |
|
Linux RHEL 5.6/6.x /SLES 11 SP1/SLES 10 SP4 /OS Independent |
|
DOS NDIS 2/ODI / EFI 1.1/UEFI 2.1/ VMware® Workstation/Vmware ESX 4.02 |
Model |
Description |
LREC9801BF-SFP+ |
Intel 82599 PCIe x8 10Gbps Single Port Fiber Server Adapter(1x SFP+) |
LREC9802BF-2SFP+ |
Intel 82599 PCIe x8 10Gbps Dual Port Fiber Server Adapter(2x SFP+) |
LRXP8510-X3ATL |
SFP+ Duplex 10Gbps 3.3V Multi-Mode Transceiver ,850nm 0.3km |
LRXP1310-10ATL |
SFP+ Duplex 10Gbps 3.3V Single-Mode Transceiver, 1310nm , 10km |
SFP+-10G-CUxM |
SFF-8431 10G SFP+ DAC (Direct Attach Copper) 1M,3M,5M,10M |
PS: The above details are just for reference,if there are any changes,no inform will have.
