Specifications
|
Controller |
Intel X710 |
|
|
Cable medium |
Copper |
|
|
Fiber Type |
CAT-5 |
50M(10Gbps);100M(5Gbps); |
|
CAT-6 |
50M(10Gbps);100M(5Gbps); |
|
|
CAT-6e |
50M(5Gbps); |
|
|
Bracket Height |
SFF |
|
|
Power (min) |
3.696 W |
|
|
Power (max) |
7.14 W |
|
|
System Support |
Windows 8 /8.1 /10 /11 |
|
|
Windows Server 2012 /2016 /2019 /2022 |
||
|
RHEL/CentOS 7.3 /7.6 /7.9 /8.3 |
||
|
Deepin 20 /20.6 |
||
|
Ubuntu 16.04.3 /18.04.5 /20.04.1 |
||
|
SUSE 15.4 |
||
|
FreeBSD 13.2 /12.2 |
||
|
ZTE New Fulcrum 3.2.2 /5.0.5 |
||
|
Asianux Server V7.0 |
||
|
Galaxy Unicorn V10 /V10 SP1 |
||
|
NeoKylin 7.6 |
||
|
Zhongke Fangde desktop operating system 4.0 |
||
|
Zhongke Fangde server operating system |
||
|
Tongxin UOS 20 |
||
|
Emind |
||
|
NeoKirin 0.7.5 |
||
|
VMware ESXi 6.7 /7.0 |
||
|
Mikrotik |
||
|
iKuai router |
||
|
Bus Type |
OCP3.0 SFF |
|
|
Data rate per port |
100/1000Mbps/2.5/5/10Gbps |
|
|
Connector |
2*10G RJ45 |
|
|
Power Supply |
OCP |
|
Technical Features
|
Protocol Support |
IEEE 802.3an 10GBASE-T Ethernet IEEE 802.3bz 2.5/5GBASE-T Ethernet IEEE 802.3ab 1000BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3az - Energy Efficient Ethernet (EEE) IEEE 802.3z IEEE 802.1Q VLANs IEEE 802.3x IEEE 1588 |
|
PXE |
Yes |
|
DPDK |
Yes |
|
WoL |
No |
|
iSCSI |
No |
|
Jumbo Frames |
Yes |
|
IEEE 1588 |
Yes |
|
SR-IOV |
Yes |
|
Jumbo data frame MAX |
9.7KB |
|
ESD_Contact discharge |
±6KV (Class C) |
|
ESD_Air discharge |
±8KV (Class C) |
ESD test classification
Class A: Normal performance within the limits specified by the manufacturer, commissioner, or purchaser.
Class B: Temporary loss or reduction of function or performance, but can be recovered by itself after the disturbance stops, without operator intervention;
Class C: Temporary loss or degradation of function or performance that requires operator intervention to restore;
Class D: irrecoverable loss of function or performance degradation due to damage to device hardware or software, or loss of data.
Environment Features
|
Operating Temperature |
0℃ to 50℃ (-32 ℉ to 122 ℉) |
|
Storage Temperature |
-40℃ to 70℃ (-40℉ to 158℉) |
|
Storage Humidity |
Maximum: 90% non-condensing relative humidity at 35 ℃ |
|
Certification |
FCC, CE, RoHS |
Physical Features
|
PCB Size(mm) |
115*76*1.6 |
|
Package Size(mm) |
179*150*30 |
|
Weight(g) |
* |
LED Indicators
|
100/1000Mbps/ 2.5/5Gbps |
LINK |
Orange Link |
|
ACT |
Orange Blink |
|
|
10Gbps |
LINK |
Orange Link + Green Link |
|
ACT |
Orange Blink + Green Link |
Order Information
|
P/N |
Description |
|
LRES3021PT-OCP |
OCP 3.0 Dual-Port 10G Copper Ethernet Network Adapter (Intel X710) |
PS: Above details are only for reference, if there is any change,no prior notice.
