LRES2001PT-POE is single-port copper Gigabit Ethernet PCI Express x1 PoE industrial adapter based on Inetl I210 chip, compatible with PCIe x4, x8, and x16 channels. This server adapter is mainly designed for industrial field visual inspection servers and devices, visual field clients, fast Ethernet data transmission equipment etc, as well as general servers.
LRES2001PT-POE allows power to be supplied to connected devices, such as PoE-based Gigabit cameras in machine vision inspection systems, without the need to use separate PoE injectors for those applications.The interface designed for industrial-grade cable accessm with LR-LINK customized industrial cable can more securely lock the cable and network port, effectively solve the problem of unstable network ports and cable connections in industrial sites, also compatible with ordinary cable access.
|
Controller |
Intel I210 |
|
Transmission Rate Per Port |
10/100/1000 Mbps |
|
Network Standard Physical Layer Interfaces |
1000BASE-T:Cat 5eor higherup to 100m |
|
100BASE-Tx:Cat5e/6or higherup to 100m |
|
|
Jumbo Frame Support |
Up to 9.5 KB |
|
Operating Temperature |
0 °C to 55°C (32 °F to 131°F) |
|
Boot Option and Virtualization |
PXE support, Intel® VT-c |
|
LED Indicators |
1000Mbps/s:Yellow Link and Green Ack, |
|
100Mbps/s:Green Link and Green Ack |
|
|
POE Output |
Supports PoE+ ports up to 30W at 48V DC |
|
Operating System Support |
Windows Server2008 /2008 R2 / 2012 /2012 R2 /2016 R2 |
|
Windows7 / 8 / 8.1 / 10 |
|
|
FreeBSD 9 /10or later |
|
|
Linux Stable Kernel version 2.6.x/ 3.x/ 4.xor later |
|
|
VMwareESX/ESXi5.x/6.xor later |
ORDERING INFORMATION
PS: The above details is just for reference, if there is any change, no inform will have.
PCI Express x1 Single Port 802.3at PoE+ Gigabit Vision Frame Grabber Card (Based on Intel I210)
.jpg)
PCI Express x1 Single Port 802.3at PoE+ Gigabit Vision Frame Grabber Card (Based on Intel I210)
.jpg)
PCI Express x1 Single Port 802.3at PoE+ Gigabit Vision Frame Grabber Card (Based on Intel I210)
PCI Express x1 Single Port 802.3at PoE+ Gigabit Vision Frame Grabber Card (Based on Intel I210)
