The LREC9812AF-2SFP+ is a dual-port 10Gb Ethernet network adapter featuring the next generation BCM57810 single-chip solution from Broadcom in a PCIe 2.0 compliant form factor.
Leveraging Broadcom market-proven architecture and software, the LREC9812AF-2SFP+ delivers full line-rate performance across all ports with low power consumption.
The LREC9812AF-2SFP+ 10G network adapter supports enterprise class features such as VLAN tagging, adaptive interrupt coalescing,MSI-X, NIC teaming(bonding),Receive Side Scaling (RSS), jumbo frames, PXE boot and virtualization features such as VMware NetQueue and Microsoft VMQ.
|
Network Processor Data Rate |
Broadcom BCM57810 chipset Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex |
|
|
theoretical bandwidth. |
|
Onboard Memory |
256MB |
|
Bus Type |
PCI-e 2.0 x8 |
|
Form Factor |
Standard and low profile adapter compliant with the PCIe standard |
|
IEEE Compliance |
802.3, 802.3ae, 802.3x, 802.2x, 802.3ad, 802.1Qaz, 802.1Qau, 802.1Qbb, 802.1Qbg, 802.1ax |
|
OperatingTemperature |
0 to 55 Centigrade |
|
Humidity |
5% to 95% non-condensing |
|
Power |
9W maximum |
|
Operating System Support
|
Microsoft Windows Server 2008, Server 2008R2, and HPC Server 2008, 32 and 64-bit Microsoft Windows Server Hyper-V Red HatEnterpriseLinux 5.7 and 6.1 SLES 10 and 11 VMware 4.1u2 and 5.0u1 Solaris 10 |
|
Model |
Description |
|
LREC9812AF-2SFP+ |
BCM57810 PCIe x8 10Gbps Dual Port Fiber Server Adapter(2x SFP+) |
|
LRXP8510-X3ATL |
SFP+ Duplex 10Gbps 3.3V Multi-Mode Transceiver ,850nm 0.3km |
|
LRXP1310-10ATL |
SFP+ Duplex 10Gbps 3.3V Single-Mode Transceiver, 1310nm , 10km |
|
SFP+-10G-CUxM |
SFF-8431 10G SFP+ DAC (Direct Attach Copper) 1M,3M,5M,10M |
PS: The above details is just for reference,if there is any change,no inform will have.
